上海歐朔生產的全伺服水平式卷膜制袋包裝機，可實現數據調取，一鍵式切換;全伺服結構，更加簡單穩定、噪音更小;封合采用伺服跟隨定位，減少封口允許誤差，提升包裝美觀度;設備采用全新控制系統，提升OEE設備綜合效率;具備運轉機構監視功能，更加具備安全性;設備更加智能，降低對操作人員的要求.
全伺服水平式卷膜制袋包裝機的特點及參數
EQUIPMENT FEATURE AND PARAMETER:
1.可實現數據調取，一鍵式切換;
Data retrieval ability with one-button switching facility
2.全伺服結構，更加簡單穩定、噪音更小;
Fully servo structure, simpler and more stable, less noise
3.封合采用伺服跟隨定位，減少封口允許誤差，提升包裝美觀度;
Servo-followed Poistioning sealing, reduce allowable sealing error and improves aesthetics of packaging
4.設備采用全新控制系統，提升OEE設備綜合效率;
Adopts a Fully new control system to improve the comprehensive rate of OEE equipment
5.具備運轉機構監視功能，更加具備安全性;
Equipped with running mechanism monitoring function, adding better security
6.設備更加智能，降低對操作人員的要求;
The equipment is more intelligent which reduces the requirements for operators
| 型號 Model | SF-480D | SF-360D | SF-480Q | SF-240 | SF-240D | SF-180 | ||
| 袋形尺寸范圍 Pouch Size |
90*110(Min) 240*350(Max) |
80*110(Min) 180*270(Max) |
60*80(Min) 120*225(Max) |
90*110(Min) 240*350(Max) |
60*80(Min) 120*224(Max) |
90*110(Min) 180*260(Max) |
||
| 包裝容量范圍 Filling Capacity | 2500ml | 1200ml | 180ml | 2500ml | 180ml | 1200ml | ||
| 包裝速度 Packaging Capacity | 100-140ppm | 100-140ppm | 200-260ppm | 50-70ppm | 100-140ppm | 50-70ppm | ||
| 能 耗Energy Consumption |
|
17kw/h | 18kw/h | 16kw/h | 17kw/h | 15kw/h | ||
| 耗氣量 Air Consumption | 300NL/min | 300NL/min | 400NL/min | 300NL/min | 300NL/min | 300NL/min | ||
| 設 備尺寸 Machine Dimensions |
13200*1580*1850 (L*W*H) |
11000*1700*1850 (L*W*H) |
12800*1240*1500 (L*W*H) |
9000*1500*1850 (L*W*H) |
9500*1500*1850 (L*W*H) |
7650*1500*1850 (L*W*H) |
||
| 重 量 Weight | 8300kg | 8000kg | 10800kg | 6600kg | 6900kg | 5600kg |
